StoneTalk Podcast Episode 31: Richard Ashoff

Posted on 22 February 2017 by cradmin

In this episode of Moraware’s StoneTalk podcast, host Patrick Foley interviews Richard Ashoff, president of Tylerco, which manufacturs and distributes SLABlite backlighting panels for countertops. The pair discuss several topics, including all of the following:

  • How SLABlite lights up translucent surfaces
  • Using the “wow” factor on the showroom floor to boost sales
  • How seemingly boring stone can be transformed with the proper backlighting
  • Fabricating a vanity that doubles as a nightlight

Read the full transcript of this episode here: StoneTalk Episode 31 – Richard Ashoff

Comments (0)

SLABlite Backlighting Installation

Tags: , , ,

SLABlite Backlighting Installation

Posted on 25 November 2014 by cradmin

We recently became aware of this excellent video depicting the installation of SLABlite backlighting panels from Tylerco. Backlighting countertops may be a growing trend in kitchen countertops, but videos detailing installation are still rare.

This particular video was produced by a homeowner rather than a professional contractor, and the installation of this backlit countertop was simply his Saturday afternoon project. John Seaman, the creator of the video, had no prior experience with the SLABlite product, and the video documentation of his first experience shows just how easy it is to install. As his countertop surface, he chose a translucent, natural-quartz material manufactured in Brazil known as Lumix, and the result of his handiwork speaks for itself.

If a layman can perform the work, there is little doubt that a countertop professional can have stellar results.

For further information about the increasingly popular SLABlight backlighting panels and to download a SLABlite Quick-Start Guide, visit the Tylerco website.

Comments (0)

Tags: , , , ,

Adapted: An Insider’s Perspective on Backlighting Translucent Surfaces

Posted on 18 September 2014 by cradmin

backlit surface 1By Richard Ashoff

Editor’s Note: In this blog entry, Richard Ashoff, CEO of Tylerco, Inc. sheds some light on how his SLABlite product for backlighting translucent surfaces works.

With the growing interest in backlighting translucent materials, such as onyx, glass and certain types of quartz surfacing and solid surface, a lot of questions have been coming up. In an effort to help you understand the ins and outs of the process better, specifically as it relates to our SLABlite product, I have put together this blog post.

What are lumens and have you ever been concerned about them before? Lumens per sq. ft. would refer to lights that are used to illuminate commercial areas. There are requirements that lights have to meet for building codes. However, talking about lumens really just confuses the issue and really has nothing to do with backlighting surfaces.

There are many ways lighting translucent material can be achieved. You can use light bulbs, fluorescent lamps, LED strips or LED tape, and many companies have tried them all. However, more goes into lighting translucent surfaces than the actual lights. When backlighting surfaces, the first objective is to enhance the translucence of the material being illuminated. The SLABlite is designed to throw light 1 inch. We don’t care about the rest of the environment. That is why lumens are really beside the point.

Translucent material has to be backlit as if the sun were shining through it. There can be no hot spots or shadowing. The SLABlite’s foundation is based on a light guide. A light guide is the same technology that is used to light cellphones, computer monitors, TVs and signs. You would think that this would be easy enough to do. Unfortunately, you can’t just take the light guide technology and throw it under a slab and think it will work or last for any amount of time.

backlit surface 2An average LED bulb is stated to last 50,000 hours. That is the equivalent to 5 to 7 years of continuous burn. This would be acceptable if you could easily replace the bulb, but having to replace a bulb that is under an installed heavy slab is definitely NOT easy. So, we engineered the SLABlite for an increased lifespan – a minimum lifespan of 20 years. Because we are only trying to light 1 inch away from our light (the translucent slab material), we drive our LEDs at a lesser rate, which gives us a longer life. It also reduces the heat output from the LEDs. Heat is the enemy when dealing with LEDs.

What If?
Another issue is potential failure of an LED. The SLABlite’s LEDs are wired in parallel and in series on the same panel. If an LED were to fail, the whole panel will not fail, and the other LEDs will fill the gap. The SLABlite also has a surge protector on board. You never know when there might be a surge on the electrical line. We design protection and backup so you don’t have to get a jackhammer to remove the light.

Ease of use is also an important factor. SLABlite can be custom cut on the jobsite to fit any configuration. That means you never have to send out your template to have a pre-made configuration made for a particular application. The SLABlite is modular. You can build as big or as small as you want. When you have covered the area, you simply cut the panels to fit. You can drill holes for faucets and cut around sinks as easily as cutting plastic.

Additionally, the SLABlite is waterproof. It has been installed in pools, fountains, baths, boats and cement. Rather than using a potting method to seal the LEDs in a panel, SLABlite includes patented waterproofing that allows for heat contraction and expansion. SLABlite waterproofing avoids problems that occur from natural heat expansion and contraction, which can cause LEDs to separate from the panel and expose them to the elements.

SLABlites have been in the field for more than seven years, passing the 1 million hours of burn rate in 2010. We are proud to say that we have never lost a panel. Not one.

So, when you are looking for a product, make sure you are looking at a product that was made to do what it is being used for and not a product made for another type of lighting that has been adapted for your surfaces. You may think you have a less expensive product you can adapt, but an adapted product is usually a poor substitute that will cost you aggravation and a lot of money in the end. The one made for a specific use has taken into consideration things that could happen during its lifetime and has built-in solutions for potential problems that could arise. Sometimes “cheap” isn’t.

For further information on SLABlite and the lighting of translucent surfaces, visit the Tylerco, Inc. website or contact Richard Ashoff at (949) 723-2906.

Comments (0)

Countertop Backlighting Process

Tags: , , ,

Countertop Backlighting Process

Posted on 25 July 2014 by cradmin

This video, which was produced by Tylerco Inc. (makers of the SLABlite backlighting panel system), takes the form of a slideshow that depicts the process of backlighting a countertop on a yacht. The video starts out showing the bar with a subtop and then walks the viewer through each step in laying the 12- by 12- by 0.375-in. lighting panels and cutting them to shape on-site, including the small area around a sink edge. It then shows an onyx countertop, which has obviously been fabricated in a shop and brought to the location, put down over the lighting panels. It also gives a look at how the system is powered, before showing the completed top all lit up, adding a sophisticated ambience.

A great article on the subject of backlighting translucent materials recently appeared in ISFA’s Countertops & Architectural Surfaces magazine, and more information about the SLABlite backlighting system is available here.


Comments (0)

Tags: , , , , , ,

TylerCo Offers SLABlite Backlighting Panels

Posted on 16 April 2014 by cradmin

tylerco slablite LED backlighting panelstylerco slablite LED backlighting panels installTylerCo Inc. offers SLABlite, a system for backlighting translucent materials in countertops and other applications. Suitable for backlighting onyx, translucent quartz surfacing, translucent solid surface and other translucent materials, SLABlite produces even and consistent edge to edge lighting across the whole surface. Creative lighting effects can be achieved with SLABlite’s 12- by 12- by 3/8-in.-thick LED panels. They are waterproof, generate almost no heat, last 20 years and can be easily be cut to almost any shape to accommodate curved edges and fixtures, reports the company.

SLABlite is the only backlight that can be custom cut on site. An installer can cut and shape SLABlite to fit around the sink, overhangs and edges as well. There is no need for templates and trips back to the shop to cut and shape the lighting. The light panels run on a 12-volt system and requires only 2 watts of power per sq. ft.

SLABlite eliminates uneven lighting, dark spots and hot spots, and because the panels are waterproof, this makes the SLABlite suitable for fountains, pools, spas, etc. The SLABlite has a 20-year/200,000-hour lifespan, making them a solid choice for backlighting countertops.

TylerCo is proud to report that its SLABlite installations have surpassed a million hours of use without having a single failure.

For more information, visit www.tylercoinc.com/slablite.html.
